The Steel Network (VTX400-24-12ft) VertiTrack® VTX - Exterior Deflection Track with VertiClip SL Pre-Installed for Light Steel Framing 12' x 24" x 4" x 68mils (14ga)

Product Description

The VertiTrack® VTX is a deflection track system featuring preinstalled VertiClip® SLs, designed for connecting exterior cold-formed steel curtain wall studs to the primary structure at the head of the wall. It accommodates up to 1½” of vertical deflection (¾” up and ¾” down), ensuring structural flexibility. Pre-installed VertiClip® SLs at 16” or 24” spacing enhance installation efficiency, while TSN's patented Step Bushing Technology guarantees smooth, friction-free movement for seamless vertical deflection.

Product Information

• Sold per piece
• Dimensions: 12' x 24" x 4" x 68mils (14ga)
• Allows for vertical deflection of curtain wall studs at the head of wall connection to the primary structure.
• Load-rated positive mechanical attachment at each stud
• Patented Integrated Break-Away Step Bushings for friction-free vertical deflection
• Eliminates loose friction-held assemblies, heavy deep-leg track, & top row of wall bridging/strapping
• Load-rated #12 screws provided for secure vertical deflection connection to stud web
• Manufactured with certified, 68mil, 50ksi cold-formed steel for durability
